Your present location:Home >> Product >> Load Cell >> DY-JXH-S4 Multi-junction Box For load cell
  • Product name: DY-JXH-S4 Multi-junction Box For load cell
  • Product number: 140
  • Shelf time: 2017-08-22
  • Views : 143

CALT Metal Junction Box For load cell



The junction box is used for load cell.

have options of triple, Four in one, Six in one, Eight in one,Ten in one.



 DY-JXH-S4Multi-junction box with aluminium alloy enclosure, with the capacity of anti-jamming.

 With waterproof sealing joints and rubber gasket,have good waterproof dustproof performance.

 With sensitivity matching adjustment mode, each output can be balanced.

 Canprevent the damage to the sensor caused by indirect lightning and surge signal.

 Convenient in assembly and alignment.

 High Reliability.



Technical index

Technical index



 Unit

Multi-way input

0-20

mV

 Single output

0-20

mV

Accuracy

≤±0.1

%F•S

Supply voltage

12,24

VDC

Operating temperature

-20~85

Protection grade

Ip67



Joint

3/4/6/8/10
